Bending_of_beam_apparatus_stand_type

Y by Bending of Beam Stand type

Amtech India offers experimental setup to determine young’s modulus of beam by uniform and non uniform bending using the Stand pattern model . The apparatus consists of a heavy metal beam one meter long, resting on a stand with two pillars . . Two hangers with pin at the top are also provided for suspending a slotted weights. Offered with two sets of slotted weights of 500 gm x 5, one meter scale and Travelling microscope.

Categories: ,

Description

Amtech India offers experimental setup to determine young’s modulus of beam by uniform and non uniform bending using the Stand pattern model . The apparatus consists of a heavy metal beam one meter long, resting on a stand with two pillars . . Two hangers with pin at the top are also provided for suspending a slotted weights. Offered with two sets of slotted weights of 500 gm x 5, one meter scale and Travelling microscope.
