Overhead Projector
Amtech India Overhead PRojector brings sharp image via hand written illustration graphs, pictures and diagrams on transparent material, gives uniforms illuminations even at highly elevated positions of the image.
- To pick up today
- # 3-B, Durga Nagar, Ambala Cantt-133001, Haryana (India)
- Free
Amtech India Overhead PRojector brings sharp image via hand written illustration graphs, pictures and diagrams on transparent material, gives uniforms illuminations even at highly elevated positions of the image. It does not require to dimming lights. It incorporates best optics and rigid quality control. Continuous writing from top to bottom or left to right on 15 meter long cellophane roll. Cooling system to projector overheating is offered by cross flow fan , the stage temperature is maintained at 45C approx.
Thermocole packing for safety during transportation and idle time.
Technical Specification:-
1. Projection Lens : One Element 254mm
2. Condenser System : Frensnel Condenser
3. Projection Lamp : 24V-250Watt
4. Projection Platforem: 250mmx250mm
5. Lumens : 1600
6. Cooling System : Blower Cooled
7. Power Cable : Detachable Power Cable
8. Lamp Safety : Solid-state Electronic control for light intensity variations.
9. Focussing : Fine Focussing with rack &
pinion mechanism
10. Folding : Folding Arms
11. Dimensions : 310mm(W)x 310mm(D)x210mm(H)
12. Power Source : AC 220-240V
Packing:-With thermocole in sturdy cardboard box.
