Halls Effect Experimental Setup

Amtech India offers Halls Effect Experimental setup for use in Physics Laboratories. The set up consists of the following :

> High Quality Electromagnet of 7.5 Kg
> Power supply for electromagnet 0-100V/4 Amp with meter mounted on the front panel
> Germanium crystal mounted on a PCB with four connectors/probes. Four wires for crystal connections are
provided with banana plugs at the end.
> Constant current power supply 0-20 mA fitted with two digital meters for Hall voltage & crystal current.
Provided with banana sockets for connection with the crystal
> Gauss meter digital, Range:0-20 K Gauss. The instrument is provided with two scale ranges of 2k Gauss,
20k Gauss.
> Hall probe made of highly pure Indium Arsenide Crystal and is encapsulated to a non-magnetic sheet of
5mm x 4mm x 1mm (approx.) and is connected to a three feet cable. A removable cap is provided for protection
of the probe.
> Wooden stand to hold the probe and crystal arrangement between the two poles of the electromagnet

We are committed to the continuous development of our products, and therefore reserve the right to amend
specifications without prior notice
