Dual Channel DC regulated Power Supply

Amtech India Offers Dual Channel DC Regulated Power Supply with constant Voltage & Current limit type supplies, have high regulation for Load & line Voltage variation. The supply can be use in independent & current tracking made. The supply are protected against short circuit & over load. The output current can be limited to any value from 0 to maximum.

INPUT VOLTAGE : 230V + 10% AC 50 Hz

LOAD REGULATION (CV) : ± 0.05 % ± 3mV From no load to full load LOAD REGULATION (CC) : + 0.05% + 1mA From no load to full load
LINE REGULATION (CV) : ± 0.01 % ± 3mV for +10% variation input voltage LINE REGULATION (CC) : + 0.01% + 1mA for +10% variation input voltage
OPERATING MODE : Independent & Tracking mode.

RIPPLE : Less than 1mV

METER : Four Analog meters to monitor the output voltage & current of A &
B supply

PROTECTION : Against Short circuit & overload.

With Four Analog Meters Output Voltage/Current

a) 0 – ±15V/1 Amps

b)  0 – ±15V/2 Amps

c)  0 – ±30V/1 Amps

d)  0 – ±30V/2 Amps
